Cometic Multi-Layer-Steel (MLS) head gasket for Honda 1.8L B18C and 1.6L B16A motors.
Cometic MLS head gaskets are made of three layers of stainless steel, with outer layers coated in Viton (material that is heat resistant to 250 C/ 482 F). MLS gaskets provide maximum sealing performance for today’s high output engines and require no sealants.
Thickness: 0.762mm / 0.030”, 1.016mm / 0.040” or 1.295mm / 0.051"
Cometic uses Stainless steel for increased strength, it's ability to rebound, and its corrosion resistance. The outer layers of the gasket are embossed and coated on both sides with a fluoroelastomer rubber based material (viton) designed to meet the demands of a variety of harsh sealing environments, load conditions and surface finishes. The Viton coating is heat resistant to 250°C or 482°F. The center or shim layer of the gasket is comprised of an uncoated stainless steel layer, which varies in thicknesses to meet the needed requirements. MLS gaskets are ideal for both aluminium heads to cast iron blocks as well as aluminium head to aluminium blocks. They can withstand the shearing force created by the two materials. The composition of MLS will also withstand the shearing forces created by aluminium heads on cast iron blocks. No re-torque is necessary. By design the MLS gasket promotes an even torque load across the sealing surface allowing for measurable reduced bore distortion.
